connect USB to your pc, open device manager and find COM port number, open putty, select serial, and change COM port number, “Baud rate” value may vary.
![](http://cdn-5f8f2694c1ac1811c803f1bc.closte.com/wp-content/uploads/2024/07/How-to-configure-HPE-MSA-controller-IP-manually-using-cli-port.png)
Default User name is ” manage”
Default Password is ” !manage ”
Since there are 2 controllers you have to select A or B then type command in the following syntax.
set network-parameters ip address netmask netmask gateway gateway controller a|b
I am changing “B” controller in the tutorial, so it will looks like this.
set network-parameters ip 10.150.239.102 netmask 255.255.255.0 gateway 10.150.239.245 controller b
set network-parameters ip 10.150.239.102 netmask 255.255.255.0 gateway 10.150.239.245 controller b
Warning: IP address has been detected as already in use on the local area network.
Do you still want to continue? (y/n) y
Success: Command completed successfully. – Request to set network parameters has been initiated. Please allow up to two minutes for the operation to complete. In the case of failure, previous settings will be restored. (2022-06-23 19:07:54)
show controllers
Controllers
Controller ID: A
Serial Number: ACM266T13R
Hardware Version: 3.1
CPLD Version: 1.9
MAC Address: 00:C0:FF:65:D4:91
WWNN: 207000C0FF65A431
IP Address: 10.150.239.101
IP Subnet Mask: 255.255.255.0
IP Gateway: 10.150.239.254
Disks: 24
Virtual Pools: 0
Disk Groups: 0
System Cache Memory (MB): 8192
Host Ports: 4
Disk Channels: 2
Disk Bus Type: SAS
Status: Operational
Failed Over to This Controller: No
Fail Over Reason: Not applicable
Multi-core: Disabled
Health: OK
Health Reason: Health Recommendation:
Position: Top
Phy Isolation: Enabled
Controller Redundancy Mode: Active-Active ULP
Controller Redundancy Status: Redundant
Controllers
Controller ID: B
Serial Number: ACM266T157
Hardware Version: 3.1
CPLD Version: 1.9
MAC Address: 00:C0:FF:65:D6:41
WWNN: 207000C0FF65A439
IP Address: 10.150.239.102
IP Subnet Mask: 255.255.255.0
IP Gateway: 10.150.239.245
Disks: 24
Virtual Pools: 0
Disk Groups: 0
System Cache Memory (MB): 8192
Host Ports: 4
Disk Channels: 2
Disk Bus Type: SAS Status: Operational
Failed Over to This Controller: No
Fail Over Reason: Not applicable
Multi-core: Disabled
Health: OK
Health Reason:
Health Recommendation:
Position: Bottom
Phy Isolation: Enabled
Controller Redundancy Mode: Active-Active ULP
Controller Redundancy Status: Redundant
Success: Command completed successfully. (2022-06-23 19:08:00)
#
Ref- https://gist.github.com/impiza/6a6620fc7f4459e5d376901d76355d15
